2022 KUKA KR210 R2700 PRIME industrial robot

KUKA KR 210 R2700 prime is a heavy-duty 6-axis articulated industrial robot from KUKA’s KR QUANTEC prime family. It is designed for demanding applications requiring high payload capacity, long reach, and reliable positioning. Typical applications include material handling, machine tending, palletizing, automotive manufacturing, welding, assembly, and handling of large components.

The robot provides a 210 kg rated payload and 2,696 mm maximum reach, with a ±0.06 mm pose repeatability. It weighs approximately 1,111 kg and is designed primarily for floor installation.

Key Specifications:

Robot type: 6-axis articulated industrial robot
Rated payload: 210 kg
Maximum reach: 2,696 mm
Rated total load: 260 kg
Repeatability: ±0.06 mm
Robot weight: Approx. 1,111 kg
Mounting: Floor
Protection: IP65; wrist IP65
Controller: KUKA KR C4
Typical applications: Material handling, machine tending, palletizing, welding, automotive production, assembly, and heavy-component handling
