FANUC M-710iC/50 is a compact, high-speed 6-axis articulated industrial robot designed for medium-payload automation. It is particularly suitable for machine tending, material handling, grinding, polishing, deburring, water-jet cutting, washing, and general manufacturing automation. FANUC highlights its slim wrist, rigid arm, and small footprint for fast handling of larger workpieces.
The robot provides a 50 kg payload and 2,050 mm reach, with ±0.03 mm repeatability. Its relatively high axis speeds make it suitable for applications where both productivity and accurate positioning are important.
Key Specifications:
Robot type: 6-axis articulated robot
Payload: 50 kg
Maximum reach: 2,050 mm
Repeatability: ±0.03 mm
Robot weight: Approx. 560 kg
Mounting: Floor, angle, or inverted
Protection: IP54 standard; IP67 optional body protection; IP67 wrist/J3 arm
Controller: FANUC R-30iB Plus
Typical applications: Machine tending, material handling, grinding, polishing, deburring, water-jet cutting, washing, and general automation |
